| Model | WL-AHBG75 | WL-AHBG85 | WL-AHBG100 | WL-AHBG125 | WL-AHBG160 | WL-AHBG200 |
|---|---|---|---|---|---|---|
| Wheel Dia | 75mm | 85mm | 100mm | 125mm | 160mm | 200mm |
| Tread Width | 25mm | 25mm | 30mm | 37mm | 40mm | 40mm |
| Top Plat Size | 81*67mm | 100*80mm | 100*80mm | 100*80mm | 135*105mm | 135*105mm |
| Hole Spacing | 45*61mm | 60*80mm | 60*80mm | 60*80mm | 75*105mm | 75*105mm |
| Hole Dia | 8mm | 8mm | 8mm | 8mm | 10mm | 10mm |
| Load height | 94mm | 105mm | 130mm | 155mm | 195mm | 235mm |
| Load Capacity | 50kg | 55kg | 70kg | 100kg | 150kg | 180kg |
Adjust brackets, axles, brakes, and casters for cold storage as needed
Advantages of Grey Soft Rubber Wheel:
Multiple size options: small and medium-sized wheel diameters, balancing flexibility and load-bearing capacity, not taking up too much space like large wheels, and more suitable for slightly heavier loads than small wheels.
Silent: Rolling noise on hard surfaces is much lower than that of hard nylon wheels.
Shock absorption: It can absorb the vibration caused by uneven ground and protect the goods on the car (especially fragile items) from the impact of bumps.
Not damaging the floor: It is very friendly to epoxy flooring, wooden flooring, ceramic tiles, and other floors, leaving no marks or scratches.
Flexible and labor-saving: moderate rolling resistance, flexible steering
Fork Option:Swivel top plate,rigid,swivel thread plate,swivel grip ring stem,swivel square stem,adapter stem,swivel hollow rivet.
Braking: You can choose to use the upper brake, side brake, or no brake
Bearing:central precision ball bearing,double ball bearing,delrin bearing,roller bearing,plain bore.
WheelDes Option:Nylon,Hi-temp Nylon,Twin-wheels Nylon,Thermo Plastic Rubber,TPR on Aluminum,Conductive TPR,Twin-wheels TPR,Rubber,Rubber on cast Iron,Conductive Rubber,Elastic Rubber,Rubber on Cast Iron,Rubber on Aluminum,Stainiess Steel Com Rubber,Soft Rubber,Hard Rubber,Polyurethane,PU on Cast Iron,Skidproof PU,PU on Aluminum,Twin-wheels PU,Polypropylene,PVC.
Wheel Calor:black,white grey,red,claret,yellow,orange,blue,green,coffee,sliver,natural color.
Series:industrial caster series,European-style caster series,mesical caster series,light duty caster series,medium/light duty caster series,ML duty nylon twin wheel caster series,mediun duty caster series,heavy duty caster series,absorber caster series,furniture caster series,ball caster series.
